TB 11-6625 -3263-25
SPECIFICATIONS
AC Voltage Range: 0 to 750 V 2% +50 digits
DC Voltage Range: 0 to 1000 V .05% +3 digits
AC Current Range: 0 to 10 A 2% +50 digits
DC Current Range: 0 to 10 A .5% +2 digits
Decibels (dB) Range: -58 to +30 dBm
Overload protection is at least 50% of full scale deflection.
Dimensions: 3.5" x 9.25" x 10.75"
Weight: 3 lbs, 14 oz
Manuals:
TB 9-6625 -1986 -35
TM 11-6625-3055-14
TM 11-6625-3055-24P
DMWR 11-6625-3055
Items Replaced and Removed from Field
Designator
LIN
NSN
Condition Code
NOTE
See Condition Code I15.
Items Potentially Replaceable
Designator
LIN
NSN
Condition Code
NOTE
See Condition Code I15.
Condition Codes
Code
Condition
I15
The AN/USM-486A was procured to satisfy shortages of the AN/USM -
486. The AN/USM -486A will not replace the AN/USM-486, it will be
issued to users who require the AN/USM-486. The AN/USM-486 and the
AN/USM-486A are functionally equivalent. The AN/ USM -486A can
replace all items replaced by the AN/USM-486.
4-51
