TB 9-6625-2112-35
IDENTIFICATION AND DESCRIPTION
1. Test Instrument
Identification.
This bulletin provides instructions for the
manufacturer's manual was used as the prime data source in compiling these instructions.
The equipment being calibrated will be referred to as the TI (test instrument) throughout
this bulletin.
a. Model Variations. Variations among models are described in text.
b. Time and Technique. The time required for this calibration is approximately 4
hours, using the dc and low frequency techniques.
2. Forms,
Records, and
Reports
a. Forms, records, and
reports required for calibration personnel at all
levels are
prescribed by TB 750-25.
b. Adjustments to be reported are designated (R) at the end of the sentence in which
they appear. When adjustments are in tables, the (R) follows the designated adjustment.
Report only those adjustments made and designated with (R).
3. Calibration
Description. TI
parameters and
performance specifications which
pertain to this calibration are listed in table 1.
Test instrument
parameters
Performance specifications
Repetition rate
Range: 10 Hz to 1 MHz
Amplitude
Range: 80 mV to 100 V into 50 Ω load
Pulse width
Range: 50 ns to 10 ms
Delay/advance
Range: 1 s to 10 mS
Rise and fall time
Range: 0.1 MHz
Accuracy: 13 ns or less for amplitude of 50 V and below
Aberrations
Overshoot: 5% or less
Preshoot: 2% or less
Droop: 6% or less
