TB 9-6625-2296-35
b. Press POWER key ON and allow 1 hour for equipment warm-up.
NOTE
Before starting calibration make sure TI has the latest
software. In the upper right portion of the screen the software
version will be listed (Ex. TS-4317 V. X.XX, PL-1536/GRM V.
X.XX). To find out the latest software version go to the USATA
website and look under the following headers: Calibration
Support>CALSETS 2000>CAL 2000 Program>Integrated
Calibration Environment (ICE) Product Team>AN/GRM-122
Software Updates. Update software if applicable.
c. Connect calibration key to MIC/ACC IN/OUT.
NOTE
If no auxiliary box is connected to TI rear panel SCSI, TI SCSI
must be disabled in d below prior to performing self test in e
below. Do not perform d below if Auxiliary Box is connected to
TI rear panel SCSI.
d. Press key sequence listed in (1) through (5) below:
Meters Menu
(1) MODE MTRS ..............................
Auxiliary Functions Menu
(2) AUX (F6) ......................................
Configure submenu
(3) DATA ENTRY 5..........................
Configure SCSI
(4) DATA ENTRY 3..........................
Operation Mode off
(5) DATA ENTRY ENTER ..............
e. Press key sequence listed in (1) through (14) below:
Meters Menu
(1) MODE MTRS ..............................
Auxiliary Functions Menu
(2) AUX (F6) ......................................
Calibration Menu
(3) DATA ENTRY 1..........................
Cal message Menu
(4) Cal msg (F1) ................................
Toggle to off
(5) Enable Messaging .....................
Cal message Menu
(6) ESC (F6) .........................................
Auxiliary Functions Menu
(7) AUX (F6) .........................................
Recall Parameters Menu
(8) MEMORY RCL ...........................
(9) FIELD SELECT ⇑ ......................
Highlight 10. Factory Defaults
Factory Defaults recall
(10) DATA ENTRY ENTER............
9
