TB 11-6625 -3263-25
Condition Codes
Code
Condition
E87
The AN/GSM -45 can perform the following test: continuity, RF attenuation
and insulation breakdown. The range of the instrument in the RF
attenuation test Is 0 to -102 dB. The TEMOD item can perform the
continuity test and the RF attenuation test using a different technique. The
TEMOD item has a range in the RF attenuation test of 0 to -50 dB. The
TEMOD item does not measure insulation breakdown. If the user requires
an insulation breakdown test or an RF attenuation test from -50 to -102
dB, the TS-4165 does not replace the AN/GSM -45. In all other cases,
replace the AN/GSM -45 with the TS-4165.
No type designator assigned. Commercial make and model number
I1
appears in Type Designator column.
Item will not be removed from the field at this time; however, item is
P1
replaceable by TEMOD item. This item will be LCC B (if type classified)
and is technically suitable for retention against authorizations for the
standard TEMOD LCC A item. (i.e., Objective is to fill shortages with
suitable item pending availability of LCC A item.)
Item does not have a LIN; however, item is capable of being replaced by
P2
TEMOD item and will eventually be removed from the field by attrition. Unit
should take action to update authorization documents to include TEMOD
item. (i.e., Objective is to get MTOE's/TDA's updated.) Following formal
authorization and requisition, the TEMOD item will be issued.
P3
Item removed from the field in certain applications; see applicable "E"
code/s.
TEMOD item cost is substantially greater than target replacement item.
T4
Replacement determined by economics.
4-150
