TB 9-6625-2294-35
(27) Connect oscilloscope calibrator SOURCE/MEASURE CHAN 1 to CH 1 using
X10, X5, and X2 attenuators. Adjust oscilloscope calibrator EDGE output for 5 divisions of
display.
(28) Adjust ∆ control for best front corner.
(29) Press and release upper TRIGGER COUPLING pushbutton. Display readout
will indicate: ADJ ∆ (step) 5, 5 mV, 10 ns.
(30) Remove X2 attenuator from setup and adjust oscilloscope calibrator EDGE
output for 5 divisions on display.
(31) Adjust ∆ control for best corner.
(32) Press and release upper TRIGGER COUPLING pushbutton. Display readout
will indicate: ADJ ∆ (step) 6, 20 mV, 10 ns.
(33) Remove X5 attenuator from setup and adjust oscilloscope calibrator EDGE
output for 5 divisions of display.
(34) Adjust ∆ control for best front corner.
(35) Press and release upper TRIGGER COUPLING pushbutton. Display readout
will indicate: ADJ ∆ (step) 7, 50 mV, 10 ns.
(36) Replace X10 attenuator in setup with X5 attenuator and adjust oscilloscope
calibrator EDGE output for 5 divisions of display.
(37) Adjust ∆ control for best front corner.
(38) Press and release upper TRIGGER COUPLING pushbutton. Display readout
will indicate: ADJ ∆ (step) 8, 100 mV, 10 ns.
(39) Replace X5 attenuator in setup with X2 attenuator and adjust oscilloscope
calibrator EDGE output for 5 divisions of display.
(40) Adjust ∆ control for a spike on front corner of 4 to 5 percent.
(41) Press and release upper TRIGGER COUPLING pushbutton. Display readout
will indicate: ADJ ∆ (step) 9, 200 mV, 10 ns.
(42) Remove X2 attenuator from setup and adjust oscilloscope calibrator EDGE
output for 5 divisions on display.
(43) Adjust ∆ control for a front corner overshoot of 4 to 5 percent.
(44) Press and release upper TRIGGER COUPLING pushbutton. Display readout
will indicate: ADJ ∆ (step) 10, 500 mV, 10 ns.
(45) Adjust oscilloscope calibrator EDGE output 2 divisions on display.
(46) Adjust ∆ control for a front corner spike of 4 to 5 percent.
(47) Press and release upper TRIGGER COUPLING pushbutton. Display readout
will indicate: ADJ ∆ (step) 11, 1 V, 10 ns.
(48) Adjust oscilloscope calibrator EDGE output for 1 division on display.
