TB 9-6625-2346-35
Table 1. Calibration Description - Continued
Test instrument parameters
Performance specifications
Aberrations (2236A)
Range: 2 mV/div to 0.5 V/div
Accuracy: +4%, -4%, 4% p-p
Horizontal
A sweep timing
Range: 0.5 s/div to 0.05 s/div
Accuracy: 2%
Range: (X10 mag): 50 ms/div to 5 ns/div
Accuracy: 3%
B sweep timing
Range: 50 ms/div to 0.05 s/div
Accuracy: 2%
Range: (X10 mag): 5 ms/div to 5 ns/div
Accuracy: 3%
Sweep linearity
Accuracy: 5% (measured over any 2 of the center
8 divisions)
Deflection (X-Axis)
Range: 2 mV/div to 5 V/div
Accuracy: 3%
A trigger sensitivity
10
60
100
MHz
MHz
MHz
Internal
0.35 div
1.2
div
1.5
div
External
40
150
250
mV
mV
mV
B trigger sensitivity
Internal only
0.35 div
1.2
div
1.5
div
Probe adjust
Range: 0.5 V p-p
Accuracy: 5%
Counter timer multimeter
Accuracy: 1 X 10-5 ;
Time base
1 X 10-7 (2236 opt 14)
DC Volts
Range: 0.5 to 500 V
Accuracy: 0.1% of rdg + 1 LSD
Range: 0.5 to 350 V
AC Volts
Accuracy: 1% of rdg + 6 LSD
Range:
Accuracy:
50 Ω
0.3% of rdg + 20 LSD
500 Ω
0.15% of rdg + 2 LSD
5 kΩ
0.15% of rdg + 2 LSD
50 kΩ
0.15% of rdg + 2 LSD
500 kΩ
0.15% of rdg + 2 LSD
5 MΩ
0.15% of rdg + 2 LSD
50 MΩ
0.15% of rdg + 2 LSD
100 MΩ
1% of rdg + 1 LSD
CH 1 Volts
Range: 0.5 to 500 V
DC Volts
Accuracy: 0.3% of rdg + 6 LSD
Range: 0.5 to 350 V @ 20 kHz
AC Volts
Accuracy: 1% of rdg + 6 LSD
3
