TM9-4935-294-15/2
Apparatus List for Figure 3-7
Reference
S-Band
Designation
Part No.
Description
C1401
CM05F331J03
CAPACITOR, FIXED: mica, 330 pf
CR1301-CR1308
1N457
P701
7923073
CONNECTOR
RESISTOR, FIXED: 44.2 k 1%, 1/4 w
R1301
RN20X4422F
RESISTOR, FIXED: 61.9 k 1%, 1/4 w
R1302-R1309
RN20X6192F
RESISTOR, FIXED: 10 k 1%, 1/4 w
R1310
RN20X1002F
RESISTOR, FIXED: 681 ohms 1%, 1/4 w
R1311
RN20X6810F
R1312-R1319
7923071-1
POTENTIOMETER, ADJUSTMENT: 200 ohms
RESISTOR, FIXED: 2.1 k 1%, 1/4 w
R1320
RN20X2101F
RESISTOR, FIXED: 100 ohms 10%, 1/2 w
R1401
RC20GF101K
R1403
7923071-3
POTENTIOMETER, ADJUSTMENT: 6 k
RESISTOR, FIXED: 10 k 5%, 1/2 w
R1404
RC20GF103J
RESISTOR, FIXED: 3.9 k 5%, 1/2 w
R1405
RC20GF392J
R1406
(Deleted)
R1407
7923071-2
POTENTIOMETER, ADJUSTMENT: 1 k
R1501
7923072-4
POTENTIONMETER, ADJUSTMENT: 5 k
R1502
7923070
POTENTIOMETER: 10-turn, 1 k
R1503
7923072-1
POTENTIOMETER, ADJUSTMENT: 200 ohms
R1606
7923072-3
POTENTIOMETER, ADJUSTMENT: 2 k
RESISTROR, FIXED: 475 ohms 1%, 1/4 w
*R1506
RN20X4750F
RESISTOR, FIXED: 51 k 10%, 1/2 w
VR1507
RC20GF513K
VI01
7923108
TUBE, BWO
*Nominal; value factory selected.
Change 1 3-49
