TB 9-4920-457-35
Table 7. Airspeed Indicator Check (High Range) - Continued
Test instrument
Pneumatic pressure standard indications
airspeed indications
(knots)1
(knots)
Min
Max
460
456
464
480
476
484
500
496
504
520
515
525
540
535
545
560
555
565
580
575
585
600
595
605
620
615
625
640
635
645
650
645
655
Values outside parenthesis are for part numbers 336-00001. Values inside
1
parenthesis are for part number 336-0004.
11. Final Procedure
a. Deenergize and disconnect all equipment.
b. Annotate and affix DA label/form in accordance with TB 750-25
12
