b. Connect TI to 120 V ac power source. Ensure DC power is not selected. Verify green
LED is illuminated.
c. Turn TI on by toggling DC switch up and ensure DC LED illuminates.
d. TI initial start screen will be shown momentarily. Verify TI software revision status
as shown below. (Ver X.XX indicates software revision number.)
Tel-Instrument
T-36M
Ver X.XX
YY/YY/YY
e. Turn TI off.
f. While holding TI DELETE 90/30 150/9960 switch in down position toggle TI DC
switch up. Verify TI displays the following:
Modulation Off Mode
Enter to continue
g. Press TI ENT key on keyboard to turn Modulation off.
Verify TI displays the
following:
Modulation turned
OFF
h. Remove cap from TI ANTENNA port. TI will revert to ANTENNA mode and 000
dBm will be displayed.
i. Reinstall cap on ANTENNA port. TI will return to Direct Connect mode and -025
dBm will be displayed.
j.
Turn TI off.
