TB 9-5120-202-24
Table 3. Minimum Specifications of Equipment Required.
Minimum use
Manufacturer and model
Common name
specifications
(part number)
HBM, Model MGCplus (13589298)
FORCE/TORQUE
Range: 0.1-3.06 mV/V
INDICATOR
Accuracy: 0.03% indication
CDI, Model 2000-400-02 w/ Torque
Range: 5 to 50 in-oz
LOW TORQUE
1
Accuracy: 0.5% in-oz of
Cell Model 2000-4-02
STATION
indicated, or 0.2 in-oz,
whichever is greater
TORQUE CELL NO. 1
Range: 0 to 60 in-lb
Lebow Associates, Model 2133-124-5
(MIS-26485, Type 1, CL1)
Accuracy: 0.5% applied torque
from 20% FS to FS
TORQUE CELL NO. 2
Range: 0 to 20 ft-lb
Lebow Associates, Model 2133-124-
Accuracy: 0.5% applied torque
20 (MIS-26485, Type 1, CL2)
from 20% FS to FS
TORQUE CELL NO. 3
Range: 0 to 100 ft-lb
Lebow Associates, Model 2133-125
Accuracy: 0.5% applied torque
(MIS-26485, Type 1, CL3)
from 20% FS to FS
TORQUE CELL NO. 4
Range: 0 to 500 ft-lb
Lebow Associates, Model 2133-126
Accuracy: 0.5% applied torque
(MIS-26485, Type 1, CL4)
from 20% FS to FS
TORQUE CELL NO. 5
Range: 0 to 1000 ft-lb
Lebow Associates, Model 2133-127
Accuracy: 0.5% applied torque
(MIS-26485, Type 1, CL5)
from 20% FS to FS
TORQUE TESTER
Range: 20 to 200 in-oz
AWS3002 (MIS-45850)
Accuracy: 0.5% applied torque
1 This
item is a TSC Calibration Standards Non Set Configuration (System Code U10).
Change 1
