TB 9-6625-2144-35
SECTION I
IDENTIFICATION AND DESCRIPTION
This bulletin provides instructions for the
1. Test Instrument Identification.
calibration of Radar Test Set, AN/UPM-29C and TS-147B/UP, TS-147D/UP, and
TS147F/UP. The manufacturers' manuals TM's 11-6625-917-15 and 11-1247 (Series) were
used as the prime data source in compiling these Instructions. The equipment being
calibrated will be referred to as the TI (test instrument) throughout this bulletin.
a. Model Variations. Differences among models are described in text.
b. Time and Technique. The time required for this calibration is approximately 3
hours,. using the microwave technique.
2. Forms, Records, and Reports
prescribed by TB 750-25.
b. Adjustments to be reported are designated (R) At the end of the sentence in which
they appear. When adjustments are in tables, the (R) follows the designated adjustment.
Report only those adjustments made and designated with (R).
3. Calibration Description. TI parameters and performance specifications which
pertain to this calibration are listed in table 1.
Table 1. Calibration Description
Test instrument
Performance specifications
parameters
TS-147 ( )/UP
AN/UPM-29 ( )
Frequency meter
Range: 8470 to 9630 MHz
Range: 15.7 to 17.0 GHz
2.5 MHz absolute
8 MHz absolute
Accuracy:
Accuracy:
1 MHz relative for
1.5 MHz/60 MHz
increments of less
increment
relative
than 60 MHz 1
MHz at 9310
Signal generator
Range: 8500 to 9600 MHz
Range: 15.7 to 17.0 GHz
RF output power
Range: -7 to -85 dBm
Range: -43 to -90 dBm
1.5 dB
2 dB
Accuracy:
Accuracy:
RF input power1
Range: +7 to +30 dBm
Range: +3 to +30 dBm
1.5 dB
1.5 dB
Accuracy:
Accuracy:
1Item
should be calibrated to highest cardinal point allowed by standard (Example: +7, +10, +20, +30).
2
