TB 9-6625-2262-24
12. Resistance
a. Performance Check
and COM.
(1) Connect calibrator OUTPUT HI and LO to TI V
.
(2) Set function switch to
(3) Set TI and calibrator for settings listed in table 7. At each setting, use calibrator
output adjustment controls to set calibrator control display Reading equal to TI indication.
Calibrator control display Error indications will be within limits specified in table 7.
Table 7. Resistance
Calibrator
Error
Test instrument
indications
Output
(%)
range settings
settings
0.42
320
190
0.26
3.2 k
1.9 k
0.26
32 k
19
k
0.26
320 k
190
k
0.26
3.2 M
1.9 M
1.05
32 M
19
M
Set calibrator 2 wire Comp to ON.
1
Set calibrator 2 wire Comp to OFF.
2
(4) Press RANGE pushbutton until nS is displayed.
(5) Set calibrator for a 100 M
output. TI will indicate between 9.7 and 10.3 nS.
b. Adjustments. No adjustments will be made.
13. Final Procedure
a. Deenergize and disconnect all equipment.
b. Annotate and affix DA label/form in accordance with TB 750-25.
