TB 9-6625-2282-24
Table 2. Minimum Specifications of Equipment Required.
Manufacturer and model
Common name
Minimum use specifications
(part number)
MULTIMETER
Range: 0 and ~+3.5 V dc
Fluke, Model 8846A
(8846A/G)
Resolution: 10 V
Accuracy: 0.5%
Responsivity at 810 nm: 4.83 x 10-8 V/W
DYN400
NIGHT VISION DEVICE
10.60%
(NVD) DETECTOR
GEN II High
3.15 V dc 11%
STANDARD
GEN II Low
12.7 mV dc 11%
GEN III High
1.44 V dc 11%
GEN III Low
5.4 mV dc 11%
CALIBRATION PROCESS
6. Preliminary Instructions
a. The instructions outlined in paragraphs 6 and 7 are preparatory to the calibration
process. Personnel should become familiar with the entire bulletin before beginning the
calibration.
b. Items of equipment used in this procedure are referenced within the text by common
name as listed in table 2.
c. Unless otherwise specified, verify the result of each test and, whenever the test
requirement is not met, take corrective action before continuing with the calibration.
Adjustments required to calibrate the TI are included in this procedure. Additional
maintenance information is contained in TM 11-5855-299-12&P.
d. Unless otherwise specified, all controls and control settings refer to the TI.
7. Equipment Setup
WARNING
HIGH VOLTAGE is used or exposed during the performance of
this calibration.
DEATH ON CONTACT may result if
personnel fail to observe safety precautions.
REDUCE
OUTPUT(S) to minimum after each step within the
performance check where applicable.
a. Remove TI from protective case.
b. Ensure TI II, III, OFF switch is set to OFF position.
c. Set multimeter to measure DCV, AUTO range, and select A FLTR.
d. Press ZERO on multimeter.
