TB 9-6625-2296-35
Table 1. Calibration Description
Test instrument parameters
Performance specifications
RF SIGNAL GENERATOR - CONTINUED
Phase Noise
<-90 dBc/Hz at 20 kHz from output frequency >1 MHz to <930 MHz
<-85 dBc/Hz at 20 kHz from output frequency ≥930 MHz
<-80 dBc/Hz at 20 kHz from output frequency 500 kHz to ≤1 MHz
Harmonics
<-26 dBc
Non-Harmonics
<-50 dBc
Residual AM
(Post detection BW: 50 Hz to 15 kHz)
< 0.10% RMS from 1 to 999.9999 MHz
< 0.20% RMS ≤ 1 MHz
FM Deviation
100 Hz to 25.0 kHz
Range
30 Hz to 20 kHz
Modulation Rates
5% at 1.0 thru 20.0 kHz
Accuracy
10% at 100 Hz to <1.0 kHz and >20.0 kHz to 25.0 kHz
Total Harmonic Distortion
>6 kHz deviation (sine wave only)
(sine wave only):
<0.7% (700 Hz thru 1.1 kHz); 0.3 to 3 kHz post detection filter
<1.0% (30 Hz thru 10 kHz)
<2.0% (> 10.0 thru 20.0 kHz)
AM Deviation
750 kHz to 999.9999 MHz (1 to 90%)
Range
100 Hz to 10 kHz
Modulation Rates
5% of setting (30% thru 90% mod)
Accuracy
10% of setting (30% thru 90% mod) fc ≤1 MHz
Total Harmonic Distortion (30% to 70%)
<0.7 % (700 Hz thru 1.1 kHz); 0.3 to 3 kHz post detection filter
(sine wave only)
<1.5% (100 Hz thru 6.0 kHz)
<2.5% (> 6 thru 10.0 kHz)
<5.0% (0.75 thru 1.0 MHz)
POWER METER
1.5 to 999.9999 MHz
Frequency Range
0.2 mW to 200 W (up to 30 MHz)
Level Range
0.2 mW to 100 W (>30 to 200 MHz)
0.2 mW to 50 W (>200 to 999.9999 MHz)
10% (up to 400 MHz) 1 count
Accuracy
20% (beyond 400 MHz) 1 count
3
