TB 9-6625-2356-35
Table 6.
Scale Accuracy 1000 Degrees Fahrenheit Full Scale - Continued
Multimeter reading (mV)
TI inner scale dial
setting (White 0F)3
Min
Actual
Max
Adjustment
-50
-1.8106
-1.729
-1.6477
N/A
50
0.3514
0.397
0.4423
R64
150
2.6195
2.667
2.7140
N/A
250
4.9187
4.965
5.0120
N/A
350
7.1615
7.207
7.2524
N/A
450
9.3864
9.432
9.4784
N/A
550
11.6559
11.703
11.7499
N/A
650
13.9663
14.014
14.0616
N/A
750
16.3021
16.350
16.3983
N/A
850
18.6563
18.705
18.7531
N/A
950
21.0221
21.071
21.1192
N/A
1 Perform
paragraphs b (1) through (11) below.
2 Perform
paragraphs b (1) through (8) below.
3 Set slide switch to the left white ON position.
4 Perform paragraphs b (1) through (16) below.
Table 7. Scale Accuracy 2100 Degrees Fahrenheit Full Scale
Multimeter reading (mV)
TI outer scale dial
setting (Black 0F)
Min
Actual
Max
Adjustment
100
1.4503
1.521
1.5913
R181
300
6.0241
6.094
6.1630
N/A
500
10.4909
10.561
10.6318
N/A
700
15.1070
15.179
15.2519
N/A
900
19.8134
19.887
19.9601
N/A
1100
24.5488
24.622
24.6953
N/A
1300
29.2430
29.315
29.3872
N/A
1500
33.8416
33.912
33.9823
N/A
1700
38.3207
38.389
38.4575
N/A
1900
42.6742
42.741
42.8070
N/A
2100
46.8900
46.954
47.0182
R82
TI inner scale dial
Multimeter reading (mV)
setting (White 0F)3
Min
Actual
Max
Adjustment
0
-0.7584
-0.692
-0.6262
N/A
200
6.0241
3.820
3.8915
R64
400
8.2473
8.316
8.3851
N/A
600
12.7829
12.855
12.9263
N/A
800
17.4526
17.526
17.5986
N/A
1000
22.1818
22.255
22.3287
N/A
1200
26.9051
26.978
27.0507
N/A
1400
31.5564
31.628
31.6990
N/A
1600
36.0966
36.166
36.2354
N/A
1800
40.5135
4.0581
40.6484
N/A
2000
44.8008
44.866
44.9314
N/A
1 Perform
paragraphs b (1) through (11) below.
2 Perform
paragraphs b (1) through (8) below.
3 Set slide switch to the left white ON position.
4 Perform paragraphs b (1) through (16) below.
7
