TM9-4935-294-15/2
Apparatus List for Figure 3-11
Reference
C-Band
Designation
Part No.
Description
C1401
CM05F881J08
CAPACITOR, FIXED: mica, 330 pf
CR1301-CR1308
1N467
L1401
MS75054-5
CHOKE: 1 mh
J701
7923073
CONNECTOR
R1301
RN20X4422F
RESISTOR, FIXED: 44.2 k 1%, 1/4 w
R1302
RN20Xl1503F
RESISTOR, FIXED: 150 k 1%, 1/4 w
R1303 & R1304
RN20X6192F
RESISTOR, FIXED: 61.9 k -1%, 1/4 w
R1305
RN20X3162F
RESISTOR, FIXED: 31.6 k 1%, 1/4 w
R1306-R1309
RNL0X6192F
RESISTOR, FIXED: 61.9 k 1%, 1/4 w
R1310
RN20X1002F
RESISTOR, FIXED: 10 k 1%, 1/4 w
R1311
RN20X3010F
RESISTOR, FIXED: 301 ohms 1%, 1/4 w
R1312-R1319
7923071-1
POTENTIOMETER, ADJUSTMENT: 200 ohms
R1320
RN20X2210F
RESISTOR, FIXED: 221 ohms 1%, 1/4 w
R1321
7923071-1
POTENTIOMETER, ADJUSTMENT: 200 ohms
R1401
RC20GF101K
RESISTOR, FIXED: 100 ohms 10%, 1/2 w
R1402
RC20GF821J
RESISTOR, FIXED: 820 ohms 5%, 1/2 w
R1403
7923071-3
POTENTIOMETER, ADJUSTMENT: 5 k
RESISTOR, FIXED: 10 k 5%, 1/2 w
R1404
RC20GF103J
R1405
RC20GF392J
RESISTOR, FIXED: 3.9 k 5%, 1/2 w
R1406
RL20AD431G
RESISTOR, FIXED: 430 ohms 2%, 1/2 w
R1407
7923071-2
POTENTIOMETER, ADJUSTMENT: 1 k
R1501
7923072-4
POTENTIOMETER, ADJUSTMENT: 5 k
R1502
7923070
POTENTIOMETER: 10-turn, 1 k
R1503
7923072-1
POTENTIOMETER, ADJUSTMENT: 200 ohms
R1505
7923672-3
POTENTIOMETER, ADJUSTMENT: 2 k
*R1506
RN20X6490F
RESISTOR, FIXED: 649 ohms 1%, 1/4 w
V102
7923110
TUBE, BWO
*Nominal; value factory selected.
Change 1 3-59
