TB 9-1430-201-50
b. Adjustments. No adjustments can be made.
13. Final Procedure
a. Deenergize and disconnect all equipment.
b. In accordance with TM 38-750, annotate and affix DA Label 80 (US Army
Calibration System). When the TI cannot be adjusted within tolerance, annotate and affix
DA Form 2417 (Unserviceable or Limited Use tag).
SECTION V
ESI, MODELS DV411 AND DV412
NOTE
Unless otherwise specified, verify the results of each test, and
take corrective action whenever the test requirement is not
met, before continuing with the calibration.
14. Preliminary Instructions
calibration.
b. Items of equipment used in this procedure are referenced within the text by common
name and item identification number as listed in tables 2 and 3. For the identification of
equipment referenced by item numbers prefixed with A, see table 2, and for prefix B, see
15. Input Resistance
a. Performance Check
(1) Connect resistance bridge (A2) UNKNOWN terminals between TI IN and COM
terminals, using Kelvin clips (B4).
(2) Measure TI input resistance. Resistance bridge will indicate between 9,995 and
10,005 ohms or 99,950 and 100,050 ohms, depending on input resistance (10 k ohms or 100
k ohms) of TI.
b. Adjustments. No adjustments can be made.
10
