TB 9-6625-150-24
9. Resistance
a. Performance Check
(1) Connect TI V Ωand COM terminals to resistance standard no. 1.
(2) Set TI rotary switch to LO Ω.
(3) Set resistance standard no.1 to the first applied value listed in table 4 below.
Press and hold the TI TEST pushbutton (a single beep will indicate a stable indication). TI
will indicate between 35.26 Ω and 36.74 Ω.
(4) Repeat steps (1) through (3) above for TI and resistance standard(s) settings as
indicated in table 4 below.
Table 4. Resistance
TI meter indications (Ω)
Resistance standard(#)
TI range
Applied Ω
position
Low
High
(1) 36 Ω
LO Ω
35.26 Ω
36.74 Ω
(1) 3600 Ω
Ω
3526 Ω
3674 Ω
(1,2) 3.6 MΩ
MΩ/250V
3.526 MΩ
3.674 MΩ
(1,2) 3.6 MΩ
MΩ/500V
3.526 MΩ
3.674 MΩ
(1,2) 3.6 MΩ
MΩ/1000V
3.526 MΩ
3.674 MΩ
(3) 30 MΩ
MΩ/500V
29.38 MΩ
30.62 MΩ
(4) 300 MΩ
MΩ/500V
268 MΩ
332 MΩ
(4) 1000 MΩ
MΩ/1000V
888 MΩ
1112 MΩ
b. Adjustments. No adjustments can be made.
10. Final Procedure
a. Deenergize and disconnect all equipment.
b. Annotate and affix DA label/form in accordance with TB 750-25.
