c. Unless otherwise specified, verify the result of each test and, whenever the test
requirement is not met, take corrective action before continuing with the calibration.
Adjustments required to calibrate the TI are included in this procedure. Additional
maintenance information is contained in the manufacturer's manual for this TI.
d.
When indications specified in
paragraphs 8 through 17 are not within
tolerance,
perform the power supply check prior to making adjustments. After adjustments are made,
repeat paragraphs 8 through 17. Do not perform power supply check if all other
parameters are within tolerance.
e. Unless otherwise specified, all controls and control settings refer to the TI.
HIGH VOLTAGE is used or exposed during the performance of
personnel fail to observe safety precautions. REDUCE
OUTPUT(S) to minimum after each step within the
performance check where applicable.
NOTE
When indications specified in this procedure are not within
tolerance, perform the power supply check prior to making
adjustments.
a. Set POWER switch to OFF (out).
b. Remove protective cover from TI only as necessary to make adjustments. Replace
cover upon completion of adjustments.
c. Connect TI to a 115 V ac source.
d. Position MODULATION GENERATOR controls as
listed in
(1) through (4) below:
(1) TRIGGER mode switch to CONT and TRIGGER LEVEL control fully ccw.
(2) MODULATION AM FM/SWP & PM (∅) switches to OFF (center position)
and MOD AMPLITUDE variable control fully ccw.
(3) FUNCTION switch to
(4) FREQ/PERIOD MULT (Hz/s) switch to 1K/100K and VARIABLE control
fully cw.
e.
Position main
generator controls as
listed in
(1) through (5) below:
(1) FREQ MULT (Hz) switch to 100K and VERNIER control fully cw to CAL.
(2) SYMMETRY control to OFF (ccw to detent).
(3) DC OFFSET control to OFF (ccw to detent).
