Table 1. Calibration Description - TB-9-6625-2173-350003

TB 9-6625-2173-35

b. Adjustments to be reported are designated (R) at the end of the sentence in which

they appear. When adjustments are in tables, the (R) follows the designated adjustment.

Report only those adjustments made and designated with (R).

3. Calibration Description. TI parameters and performance specifications which

pertain to this calibration are listed in table 1.

Table 1. Calibration Description

Test instrument parameters

Performance specifications

Type SC501

Vertical sensitivity

Range: 10,100 and 1000 mV/div

Accuracy:

dc to 5 MHz

Horizontal sweep

Range: 1 s to 100 ms in a 10 to 1 ratio

Accuracy: 5%

Magnifier: X5 5%

Type SC502

Vertical sensitivity

Range: 1 mV to 20 V/div; 14 steps in a 1-2-5-sequence

5 mV to 20 V/div: 2%

Accuracy:

1 and 2 mV/div: 5%

dc to 15 MHz

Horizontal sweep

Range: .2 s to .5 s/div: 20 steps in a 1-2-5 sequence

Accuracy:

Measured over center 8 divisions

50 ms/div to 1 ms/div: 2% unmagnified; 3% magnified

.5 s/div to .1 s/div, and .5 s/div to .2 s/div:

3% unmagnified; 4% magnified

Calibrator voltage

Range: 0.6 V square wave

Accuracy:

Type SC504

Vertical sensitivity

Range: 5 mV to 10 V/div; 11 steps in a 1-2-5-sequence

Accuracy:

Aberrations

dc to 80 MHz
