TB 9-6625-2279-35
a. Performance Check
(1) Connect calibrator output to TI + and COM.
(2) Set TI function/range switch to 2.5 ACV.
(3) Set calibrator initial output for 2.5 V at 400 Hz. Adjust calibrator output
controls for a 2.5 V ac indication on TI. Calibrator control Error display will indicate
between -5% and +5%.
(4) Repeat technique of (2) and (3) above for TI function/range switch and
calibrator initial output settings listed in table 5. Calibrator control Error display will
indicate between -5% and +5% for each TI indication.
Test instrument
Calibrator initial
function/range
output settings
Test instrument
switch settings
Voltage
indications
(ACV)
(V)
(Hz)
(V ac)
10
10
400
10
50
50
400
50
250
250
400
250
500
500
400
500
1 k1
1000
400
1000
1Connect
calibrator output to TI AC 1k V and COM.
b. Adjustments. No adjustments can be made.
a. Performance Check
(1) Disconnect TI inputs.
(2) Set TI function/range switch to OHM x1.
(3) Connect leads to TI + and COM. Short leads together and adjust 0Ω ADJ
control for 0 indication on Ω scale.
(4) Connect TI + and COM to resistance standard. Adjust resistance standard
for a 20Ω indication on TI. Resistance standard will indicate between 17.74Ω and
22.55Ω.
(5) Repeat technique of (1) through (4) above for TI function/range switch settings
b. Adjustments. No adjustments can be made.
