TB 9-6625-2303-24
Table 1. Calibration Description Continued.
Performance specifications1
Test instrument parameters
Plug-in element 4410-7
Frequency range: 144 to 520 MHz
Power range: 0 to 1000 watts
Accuracy: 5% of reading above 20% of full scale of power range
Plug-in element 4410-8
Frequency range: 200 to 1000 MHz
Power range: 0 to 1000 watts
Accuracy: 5% of reading above 20% of full scale of power range
Plug-in element 4410-11
Frequency range: 50 to 125 MHz
Power range: 0 to 100 watts
Accuracy: 5% of reading above 20% of full scale of power range
Plug-in element 4410-12
Frequency range: 100 to 250 MHz
Power range: 0 to 100 watts
Accuracy: 5% of reading above 20% of full scale of power range
Plug-in element 4410-13
Frequency range: 200 to 500 MHz
Power range: 0 to 100 watts
Accuracy: 5% of reading above 20% of full scale of power range
Plug-in element 4410-14
Frequency range: 400 to 1000 MHz
Power range: 0 to 100 watts
Accuracy: 5% of reading above 20% of full scale of power range
Plug-in element 4410-15
Frequency range: 1000 to 1800 MHz
Power range: 0 to 100 watts
Accuracy: 8% Full Scale
Plug-in element 4410-16
Frequency range: 1800 to 2300 MHz
Power range: 0 to 100 watts
Accuracy: 8% Full Scale
Factor switch setting multiplied by factor printed on cap of electrical plug-in unit is equal to full scale power.
1
EQUIPMENT REQUIREMENTS
calibration procedure. This equipment is issued with Secondary Transfer Calibration
Standards Sets, AN/GSM-287 and AN/GSM-440. Alternate items may be used by the
calibrating activity. The items selected must be verified to perform satisfactorily prior to
use and must bear evidence of current calibration. The equipment must meet or exceed the
to-one ratio between the standard and TI. Where the four-to-one ratio cannot be met, the
actual accuracy of the equipment selected is shown in parentheses.
5. Accessories Required. The accessories required for this calibration are common
usage accessories, issued as indicated in paragraph 4 above, and are not listed in the
calibration procedure. The following peculiar accessories are also required for this
calibration: Calibration Element, Bird Electronic Corporation, Model 4410-070, and 50 Ω
Termination, Model 160B300.
