TB 9-6625-2327-24
IDENTIFICATION AND DESCRIPTION
1. Test Instrument Identification.
This bulletin provides instructions for the
calibration of Function/Arbitrary Waveform Generator, Agilent, Model 33250A. The
manufacturer's manual was used as the prime data source in compiling these instructions.
The equipment being calibrated will be referred to as the TI (test instrument) throughout
this bulletin.
a. Model Variations. None.
b. Time and Technique. The time required for this calibration is approximately 5
hours, using the dc and low frequency and microwave techniques.
2. Forms, Records, and Reports. Forms, records, and reports required for calibration
personnel at all levels are prescribed by TB 750-25.
3. Calibration Description. TI parameters and performance specifications which
pertain to this calibration are listed in table 1.
Table 1. Calibration Description.
Test instrument parameters
Performance specifications
Range: 1mHz to 80 MHz
Acccuracy: 1 ppm per year
Output amplitude (sine wave)
Range: 10 mVp-p to 10 Vp-p (into 50 Ω)
Accuracy: 1% of setting 1 mVp-p (at 1 kHz,
>10 mVp-p, autorange on)
Flatness (sine wave)
(Relative to 1 kHz, autorange on)
<10 MHz
1% (0.1 dB)
10 MHz to 50 MHz ....2% (0.2 dB)
50 to 80 MHz .............5% (0.4 dB)
Distortion:
< 3 Vp-p
> 3 Vp-p
Harmonic distortion:
DC to 1 MHz
-60 dBc
-55 dBc
1 to 5 MHz
-57 dBc
-45 dBc
5 to 80 MHz
-37 dBc
-30 dBc
Total Harmonic Distortion:
<0.2% + 0.1 mV
Signal characteristics:
Square wave:
Rise/fall time: <8 ns
Overshoot: <5%
Asymmetry: 1% of period + 1 ns
Jitter: <2 MHz 0.01%+ 525 ps
≥2 MHz 0.1% + 75 ps
Pulse:
Overshoot:
<5%
