Table 1. Calibration Description - Continued
Test instrument
parameters
Performance specifications
DISP OUT:
Amplitude: +4.5 1 V
Pulse Width: 0.3 to 1.0 μs
Timing:
For ISLS disparity, the pulse occurs 65 1 μs after the
enable trigger.
For Mode 4 Word B disparity, the pulse is coincident with
the pulse at 19 1.0 μs.
For Mode 4 Word A, the pulse occurs 198 2 μs after the
enable trigger.
ISLS disparity takes precedents over Word A or B
disparity
G
Impedance: 90
TC TRIG
OUT:
Amplitude: +4.5 1 V
Pulse Width: 0.8 0.2 μs
Rise Time:
0.1 μs
Fall Time:
0.2 μs
Timing:
372 0.5 μs after Mode 4 pre-trigger
R
Impedance: 90
EPLY OUT:
Amplitude: +4.5 1 V
Pulse Width: 0.45 0.03 μs
Spacing:
3 pulses spaced 1.75 0.025 μs
Timing:
199.5 0.75 μs after P4
I
Impedance: 90
SLS TRIG
OUT:
Amplitude: +4 1 V
Pulse Width: 0.3 to 1.5 μs
Rise Time:
0.2 μs
Fall Time:
0.2 μs
Timing:
Trigger occurs 5.9 0.1 μs after first sync pulse of
Mode 4 interrogation.
D
Impedance: 90
EMOD OUT:
Amplitude: > 1 V
M
Impedance: 75
ARKER
STROBE OUT:
Amplitude:
+4 1.5 V
R
Impedance:
75
F I/O SECTION:
AUX MOD IN:
Amplitude:
< 0.5 Vdc for full off condition 1 to 30 Vdc for full on
condition
Pulse Width: 0.275 μs minimum
9
Impedance: 1 k
