Table 3. Accessories Required
Item
Common Name
Description and part number
B1
ADAPTER
Dual-banana plug to BNC (7909401).
B2
CABLE ASSEMBLY
Dual-banana plug to probe plus alligator clip
(7911305).
1
CABLE
60-inch, dual-banana plug to guarded
B3
two-conductor connector.
2
POWER CABLE
60-inch, NEMA plug to guarded two-conductor
B4
connector, both inputs shorted to guard,
grounded shell.
1 Supplied as accessory with chart recorder.
2 Not available at secondary transfer set. Fabricate as shown in figure 1.
Figure 1. Fabricated power cable
SECTION III
PRELIMINARY OPERATIONS
6. Preliminary Instructions.
the identification of equipment referenced by item
numbers prefixed with A, see table 2, and for prefix B,
a. The instructions outlined in this section are
see table 3.
preparatory to the calibration process. Personnel should
become familiar with the entire bulletin before beginning
WARNING
the calibration.
HIGH VOLTAGE is used during the
b. Items of equipment used in this procedure are
performance of this calibration. DEATH
referenced within the text by common name and item
ON CONTACT may result if personnel
identification number as listed in tables 2 and 3. For
fail to observe safety precautions.
5
