TB 9-4920-468-24
Table 1. Calibration Description Continued.
Test instrument parameters
Performance specifications
Wireless Diagnostic Sensor-Analog (WDS-A) - Continued
Turbo Outlet Pressure (w_x)
Range: 0 to 333 mV dc
Airbox Pressure (y_z)
Accuracy: Greater of (1.5% of reading + 0.45 mV dc) or 1 mV
Air Cleaner Pressure Drop (AA_AB)
Range: 0 to 50 mV dc
Fuel Return Pressure (AC_AD)
Accuracy: Greater of (1.5% of reading + 0.25 mV dc) or 1 mV
Wireless Transducer Kit Adapter (WLTK)
Range: 0 to 90 mV dc
25 PSI (A_B)
Accuracy: Greater of (1.5% of reading + 0.45 mV dc) or 1 mV
Range: 0 to 100 mV dc
1000 PSI (A_B)
Accuracy: Greater of (1.5% of reading + 0.50 mV dc) or 1 mV
Range: 0 to 333 mV dc
10,000 PSI (A_B)
Accuracy: (1.5% of reading + 1.6 mV dc)
Range: 0 to 4.195 V dc
Current (A_B)
Accuracy: (5% of reading + 0.08 V dc)
Range: 0 to 5000 RPM (0 to 83 Hz)
RPM (P_R)
Accuracy: 0.415 Hz
Multimeter (APN 13666158, Agilent U1252A)
All parameters
See TB 9-6625-102-24
EQUIPMENT REQUIREMENTS
calibration procedure. This equipment is issued with Secondary Transfer Calibration
Standards Set, AN/GSM-286; AN/GSM 287; or AN/GSM 440. Alternate items may not be
used by the calibrating activity. The item selected must be verified to perform satisfactorily
prior to use and must bear evidence of current calibration. The equipment must meet or
provide a four-to-one ratio between the standard and TI.
5. Accessories Required. The accessories required for this calibration are common
usage accessories, issued as indicated in paragraph 4 above, and are not listed in this
calibration procedure. The following peculiar accessories are also required for this
calibration: Acceptance Test Equipment (ATE) PN 13675099 and instrument controller
with SwiceCal software.
Table 2. Minimum Specifications of Equipment Required.
Manufacturer and model
Common name
Minimum use specifications
(part number
CALIBRATOR
Range: 0 to 32 V dc
Fluke, Model 5720A
Accuracy: 0.25%
(p/o MIS-35947)
Range: 1 to 21 V ac
Frequency: 10 Hz to 1600 Hz
Voltage Accuracy: 1.25%
Frequency Accuracy: 0.125%
