TB 9-6625-1957-35
Table 4. Ac Voltage Continued
Calibrator
Test instrument
output
Range/Function
indications
Adjustments
Amplitude
setting
Min
Max
450 V
40 Hz
500 AC VOLTS
444.4
455.6
450 V
1.0 kHz
500 AC VOLTS
446.7
453.4
180 V
20 Hz
200 AC VOLTS
177.82
182.18
180 V
1.0 kHz
200 AC VOLTS
178.72
181.28
180 V
20 kHz
200 AC VOLTS
177.82
182.18
18 V
20 Hz
20 AC VOLTS
17.782
18.218
18 V
1.0 kHz
20 AC VOLTS
17.872
18.128
18 V
20 kHz
20 AC VOLTS
17.782
18.218
1.8 V
20 Hz
2 AC VOLTS
1.7782
1.8218
1.8 V
1.0 kHz
2 AC VOLTS
1.7872
1.8128
1.8 V
20 kHz
2 AC VOLTS
1.7782
1.8218
(4) Reduce calibrator output to minimum.
b. Adjustments. No further adjustments can be made.
10. Dc Current Accuracy
a. Performance Check
(1) Set RANGE/FUNCTION switch to 2 DC mA. If TI does not indicate .0000,
perform b below.
(2) Set calibrator for an output of 1.8 mA. TI will indicate within limits specified in
first row of table 5.
(3) Repeat technique of (1) and (2) above using outputs and settings listed in
Table 5. Dc Current
Test instrument
RANGE/FUNCTION
Calibrator
Indication limits
output
setting
Min
Max
1.8 mA
2 DC mA
1.7954
1.8046
18
mA
20 DC mA
17.954
18.046
180
mA
200 DC mA
179.54
180.46
1.8 A
2000 DC mA
1795.4
1804.6
(4) Reduce calibrator output to minimum.
11. Resistance
a. Performance Check
(1) Set RANGE/FUNCTION switch to 200K OHMS.
(2) Set calibrator for a 190 k Ω nominal output.
CHANGE 2
8
