TB 9-6625-2050-35
a. Performance Check
(1) Connect multimeter to RECORDER OUTPUT (rear panel).
(2) Connect power sensor using power sensor cable (p/o TI).
(3) Set switches as listed in (a) through (c) below:
(a) CAL FACTOR % to 100.
(b) POWER REF to OFF (out) (rear panel).
(c) RANGE to 3 W.
(4) Press ZERO pushbutton and wait for meter indicators position to stabilize.
Multimeter will indicate between -0.9 and +0.9 mV dc. Release ZERO pushbutton;
multimeter will indicate between -15 and +15 mV dc.
(5) Set RANGE switch as listed in table 4. Multimeter will indicate within limits
specified.
RANGE
Results
switch
mV dc
position
Min
Max
W
-17
+17
10
W
-14
+14
30
W
-11
+11
100
W
-8
+8
300
1 mW
-5
+5
3 mW
-5
+5
10
mW
-5
+5
30
mW
-5
+5
100
mW
-5
+5
b. Adjustments. No adjustments can be made.
a. Performance Check
(1) Connect range calibrator to TI POWER SENSOR INPUT cable (supplied
with TI).
6
CHANGE 1
PIN: 049934-001
