TB 9-6625-2114-24
Paragraph
Page
SECTION
IV. CALIBRATION PROCESS FOR MULTIMETER,
HEWLETT-PACKARD, MODEL 410C
Preliminary instructions ......................................
Equipment setup...................................................
Dc voltage ..............................................................
Ac voltage ..............................................................
Frequency response ..............................................
Resistance..............................................................
Dc current..............................................................
Final procedure .....................................................
IDENTIFICATION AND DESCRIPTION
1. Test Instrument Identification.
This bulletin provides instructions for the
calibration of Multimeter, ME-26D/U and Hewlett-Packard, Model 410C.
The
manufacturers' manuals and TM 11-6625-200-15 were used as the prime data sources in
compiling these instructions. The equipment being calibrated will be referred to as the TI
(test instrument) throughout this bulletin.
a. Model Variations. Variations among models are described in text.
b. Time and Technique. The time required for this calibration is approximately 2
hours, using the dc and low frequency technique.
2. Forms, Records, and Reports
a. Forms, records, and reports required for calibration personnel at all levels are
prescribed by TB 750-25.
b. Adjustments to be reported are designated (R) at the end of a sentence in which they
appear. When adjustments are in tables the (R) follows the designated adjustment. Report
only those adjustments made and designated with (R).
3. Calibration Description. TI parameters and performance specifications which
pertain to this calibration are listed in table 1.
Table 1. Calibration Description
Test instrument parameters
Performance specifications
Multimeter ME-26D/U
Range: 0 to +1000 V 1
Dc voltage
Accuracy: 3% FS
Range: 0 to 300 V 2
Ac voltage
Accuracy: 3% FS at 400 Hz
Frequency response
Referenced to 400 Hz:
1 dB: 20 Hz to 300 MHz
3 dB: 300 to 700 MHz
See footnotes at end of table.
