TB 9-6625-2235-24
IDENTIFICATION AND DESCRIPTION
1. Test Instrument Identification.
This bulletin provides instructions for the
calibration of Spectrum Analyzer, Hewlett-Packard, Model 8558B. The manufacturer's
manual was used as the prime data source in compiling these instructions. The equipment
being calibrated will be referred to as the TI (test instrument) throughout this bulletin.
a. Model Variations. None.
b. Time and Technique. The time required for this calibration is approximately 6
hours, using the dc and low frequency and microwave technique
2. Forms, Records, and Reports
a. Forms, records, and reports required for calibration personnel at all levels are
prescribed by TB 750-25.
b. Adjustments to be reported are designated (R) at the end of the sentence in which
they appear. When adjustments are in tables, the (R) follows the designated adjustment.
Report only those adjustments made and designated with (R).
3. Calibration Description. TI parameters and performance specifications which
pertain to this calibration are listed in table 1.
Table 1. Calibration Description
Test instrument
Performance specifications
parameters
Calibrator
Frequency: 280 MHz
Power output: -30 dBm
Frequency accuracy: 300 kHz (SN 2118A and below 50 kHz)
Power output accuracy: 1 dBm
Sweep time
Range: 0.1 ms/div to 50 ms
Accuracy: 10%
Span width
Frequency range:
5 kHz to 100 MHz
Accuracy: Frequency error between any two points is less than 5% of the
indicated frequency separation
Frequency
Range: 100 kHz to 1500 MHz
Accuracy: 0 to 195 MHz, (l MHz +20% of freq span/div switch setting) 195 to
1500 MHz, (5 MHz +20% of freq span/div switch setting)
Resolution bandwidth
Range: 1 kHz to 3 MHz
Accuracy: 20%
Input attenuator
Range: 0 to 70 dB at 30 MHz
Accuracy: .5 dB per 10 dB step
Maximum cumulate error: 0 to 70 dB <1.0 dB
