TB 9-6625-2343-50
Calibrator
Test instrument
Indications
Output
Active
(% REL)
frequency
filter
Min
Max
200 Hz
50 Hz HP
98.99
101.01
2 kHz
50 Hz HP
98.99
101.01
1 kHz
300 Hz HP
98.99
101.01
10 kHz
300 Hz HP
98.99
101.01
1 kHz
3 kHz LP
98.99
101.01
100 Hz
3 kHz LP
98.99
101.01
10 kHz
15 kHz LP
98.99
101.01
1 kHz
15 kHz LP
98.99
101.01
10 kHz
98.99
101.01
>20 kHz LP
1 kHz
98.99
101.01
>20 kHz LP
(14) Reduce all outputs to minimum and disconnect equipment setup.
b. Adjustments. None
12. Audio Measurements
a. Performance Check
(1) Press TI keys as listed in (a) through (c) below:
(a) INSTR PRESET.
(b) DATA 30.0.
(c) DATA SPCL.
(2) Reset calibrator.
(3) Connect calibrator WIDEBAND OUT to TI MODULATION OUTPUT/AUDIO
INPUT using cable and termination supplied with calibrator.
(4) Set calibrator for a wideband output frequency of 50 Hz at a level of 3 V.
(5) Press calibrator NEW REF key.
(6) If TI does not indicate within limits specified in first row of table 12, perform b below.
(7) Repeat technique of step (4) above, changing only the calibrator output
frequency to frequencies listed in table 12. If TI does not indicate within limits specified in
Calibrator
Test instrument
Indications
Output
(V rms)
frequency
Min
Max
50 Hz
2.88
3.12
500 Hz
2.88
3.12
5 kHz
2.88
3.12
40 kHz
2.88
3.12
(8) Change calibrator output to a frequency of 40 kHz at a level of 100 mV.
(9) Press calibrator NEW REF key.
(10) If TI does not indicate within limits specified in first row of table 13, perform b below.
