TB 9-6695-273-35
Amplitude
Comb lines
(dB)1
(GHz)
Min
Max
1
-7
+13
2
-9
+11
4
-14
+6
6
-19
+1
8
-23
-3
10
-27
-7
12
-30
-10
14
-33
-13
16
-36
-16
18
-38
-18
1The
tolerances listed are typical values. TI may not meet the listed values and still be in tolerance so
long as any two adjacent comb lines are not more than 10 dB different in amplitude.
b. Adjustments. No adjustments can be made.
11. Final Procedure
a. Deenergize and disconnect all equipment.
b. Annotate and affix DA label/form in accordance with TB 750-25.
7/(8 BLANK)
