TB 9-6625-199-24
APPENDIX B
PERFORMANCE TABLES
Wavetek, Model 16XL
Table B-19. Calibration Description.
Test instrument parameters
Performance specifications
DC VOLTAGE
Range: 0 to 600 V dc
Accuracy: (0.5% rdg + 1 dgt)
AC VOLTAGE
Range: 0 to 600 V ac, 50 to 500 Hz
Accuracy: 200 mV ac to 200 V ac rngs, (1% rdg + 4 dgts);
600 V ac rng, (1.5% rdg + 4 dgts)
DC CURRENT
Range: 0 to 10 A dc
Accuracy: 20 and 200 mA dc rngs, (1% rdg + 1 dgt);
10 A dc rng, (2% rdg + 3 dgts)
AC CURRENT
Range: 0 to 10 A ac, 50 to 500 Hz
Accuracy: 20 and 200 mA ac rngs, (2% rdg + 4 dgts);
10 A ac rng, (2.5% rdg + 4 dgts)
Range: 0 to 20 MΩ
Accuracy: 200 Ω rng, (1% rdg + 3 dgts);
2 kΩ to 2 MΩ rngs, (1% rdg + 1 dgt);
20 MΩ rng, (3% rdg + 1 dgt)
Range: 0.001 nF to 20 μF
Accuracy: (3.5% rdg + 4 dgts)
Range: 20 Hz to 15 MHz
Sensitivity: 1 V rms @ 20 Hz to 15 MHz
Accuracy: (0.1% rdg + 2 dgts)
Table B-20. DC Voltage.
Calibrator output
Test instrument
Applied
Range
Limits (V dc)
(V dc)
(V dc)
Min
Max
180 m
200 m
179.0
181.0
1.8
2
1.790
1.810
2
20
1.98
2.02
-2
20
-2.02
-1.98
6
20
5.96
6.04
-6
20
-6.04
-5.96
10
20
9.94
10.06
-10
20
-10.06
-9.94
14
20
13.92
14.08
-14
20
-14.08
-13.92
18
20
17.90
18.10
-18
20
-18.10
-17.90
180
200
179.0
181.0
540
600
536
544
B-7
