*TB 9-6625-2049-24
DEPARTMENT OF THE ARMY TECHNICAL BULLETIN
CALIBRATION PROCEDURE FOR
SYNTHESIZER/FUNCTION GENERATOR
HEWLETT-PACKARD
MODELS 3325A( ) AND 3325B( )
Headquarters, Department of the Army, Washington, DC
1 July 2008
Distribution Statement A: Approved for public release; distribution is unlimited
REPORTING OF ERRORS AND RECOMMENDING IMPROVEMENTS
You can improve this manual. If you find any mistakes or if you know of a way to improve these
procedures, please let us know. Mail your letter or DA Form 2028 (Recommended Changes to
Publications and Blank Forms) directly to: Commander, U.S. Army Aviation and Missile Command,
ATTN: AMSAM-MMC-MA-NP, Redstone Arsenal, AL 35898-5000. A reply will be furnished to
you.
You may also send in your comments electronically to our E-mail address:
2028@redstone.army.mil or by fax 256-842-6546/DSN 788-6546. For the World Wide Web use:
https://amcom2028.redstone.army.mil. Instructions for sending an electronic 2028 can be found at
the back of this manual.
Paragraph
Page
IDENTIFICATION AND DESCRIPTION
Test instrument identification .............................
Forms, records, and reports .................................
Calibration description .........................................
EQUIPMENT REQUIREMENTS
Equipment required..............................................
Accessories required .............................................
CALIBRATION PROCESS
Preliminary instructions ......................................
Equipment setup...................................................
Harmonic distortion..............................................
Amplitude modulation distortion ........................
Square wave characteristics ................................
Ramp retrace .........................................................
Frequency accuracy ..............................................
Phase increment ...................................................
Sine wave amplitude and flatness .......................
Square wave amplitude and flatness ..................
_________
*This bulletin supersedes TB 9-6625-2049-35, dated 30 December 2004, including all changes.
