Table 1. Calibration Description - Continued
Test instrument
parameters
Performance specifications
Amplitude accuracy with dc offset
Tolerance relative to
and no attenuation (range 1) into
programmed amplitude
50 load
0.3 dB
Sine wave: .001 Hz to 100 kHz
3%
Square: .001 Hz to 100 kHz
4%
Triangle: .001 Hz to 2 kHz
6%
2 kHz to 10 kHz
4%
Ramps: .001 Hz to 500 Hz
11%
500 Hz to 10 kHz
Tolerance relative to
Function and frequency range
programmed amplitude
0.1 dB
Attenuator accuracy (these errors .001 Hz to 100 kHz
are additive with the amplitude
Attenuator ranges 2 through 8
accuracy errors)
0.2 dB
100 kHz to 10 MHz
Attenuator ranges 2 through 8
10 MHz to 20 MHz
Attenuator ranges 2 through 4
0.2 dB
0.5 dB
Attenuator ranges 5 through 8
Amplitude output
Range: 1.000 mV to 10.00 V p-p
Range: 4 mV to 40 V p-p (>500 )
Amplitude (option 002)
(high voltage output)
Accuracy: +2% of full output for each range at 2 kHz
Flatness: +10% of programmed amplitude
Dc offset
Range: +5 V dc
Accuracy: +0.4% of full peak output for each attenuator range2
Dc offset (option 002)
Range: +20 V dc
Accuracy: + (1% +25 mV) of full output for each attenuator range
Dc plus ac
Range: <1 MHz
Accuracy: +1.2%
Ramps: +2.4%
Range: >1 MHz
Accuracy: +3%
1Not
verified below 50 Hz.
lowest attenuator range where accuracy is 20 V.
2Except
EQUIPMENT REQUIREMENTS
calibration procedure. This equipment is issued with Secondary Transfer Calibration
Standards Set AN/GSM-287 and AN/GSM-705. Alternate items may be used by the
calibrating activity. The items selected must be verified to perform satisfactorily prior to
use and must bear evidence of current calibration. The equipment must meet or exceed the
to-one ratio between the standard and TI. Where the four-to-one ratio cannot be met, the
actual
accuracy
of
the
equipment
selected
is
shown
in
parenthesis.
