TB 9-6625-2155-35
(a)
Marker, Off.
(b)
View/Trace, Trace 1, View.
(c)
Marker, Delta, to 1 kHz.
(d)
Marker, More, Function, Marker Noise.
(6) Spectrum analyzer Mkr∆ will indicate less than or equal to the minimum
indication listed in table 5.
(7) Repeat technique of (2) through (6) above for remaining frequencies listed in
Spectrum analyzer
indication
Test instrument
(dB)
minimum (≤)
(GHz)
5.999
-62.5
12
-62.5
18
-62.5
b. Adjustments. No adjustments can be made.
a. Performance Check
(1) Connect equipment as shown in figure 4 below.
(2) Press TI keys as listed in (a) through (e) below.
