TB 9-6625-2230-24
IDENTIFICATION AND DESCRIPTION
1. Test Instrument Identification.
This bulletin provides instructions for the
calibration of Digital Multimeter, Fluke, Model 8060A. The manufacturer's manual was
used as the prime data source in compiling these instructions. The equipment being
calibrated will be referred to as the TI (test instrument) throughout this bulletin.
a. Model Variations. None
b. Time and Technique. The time required for this calibration is approximately 1
hour, using the dc and low frequency technique.
2. Forms, Records, and Reports
a. Forms, records, and reports required for calibration personnel at all levels are
prescribed by TB 750-25.
b. Adjustments to be reported are designated (R) at the end of the sentence in which
they appear. When adjustments are in tables, the (R) follows the designated adjustment.
Report only those adjustments made and designated with (R).
3. Calibration Description. TI parameters and performance applications that pertain
to this calibration are in table 1.
Table 1. Calibration Description
Test instrument
parameters
Performance specifications
Dc voltage
Range: 0 to 1000 V (in 5 ranges)
Accuracy:1 200 mV and 2 V (0.04% + 2)
20, 200, and 1000 V ranges (0.05% + 2)
Ac voltage
Range: 0 to 750 V in 5 ranges
Frequency: 20 Hz to 100 kHz
Accuracy:1 20 to 45 Hz: 200 mV, 2, 20, and 200 V (1% + 10)
45 Hz to 1 kHz: 200 mV (0.2% + 10)
2, 20, 200, and 750 V (to 499.9 V) (0.5% + 10)
750 V (500.0 and up) (1% + 10)
1 to 10 kHz: 200 mV (0.2% + 20)
2, 20, and 200 V (0.5% + 20)
10 to 30 kHz: 200 mV (0.5% + 40)
2, 20, and 200 V (1.0% + 40)
30 to 50 kHz: 200 mV (1.0% + 100)
2, 20, and 200 V (2.0% + 100)
50 to 100 kHz: 200 mV, 2, 20, and 200 V (3% + 200)
Dc current
Range: 0 to 2000 mA in 5 ranges
Accuracy:1 200 A and 2 mA (0.2% + 2)
20, 200, and 2000 mA (0.3% + 2)
Ac voltage, dB mode
The dB mode is a mathematical function of the 5 ac voltage ranges.
7.79 dBm (0.10 dB) is checked to verify function capability
Frequency
Range: 200 Hz, 2000 Hz, 20 kHz, and 200 kHz (fully autoranging)
Accuracy:1 (0.05% + 1)
See footnote at end of table
