(d) Toggle ▲ or ▼ to display/highlight ADD MAIN READING.
(e) (F5) SELECT ITEM.
(f) Toggle ▲ or ▼ to display/highlight V DC.
(g) (F5) SELECT ITEM.
(h) Toggle ▲ or ▼ to display/highlight READINGS on DISPLAY.
(i) (F5) SELECT ITEM.
(j) Toggle ▲ or ▼ to display/highlight 1.
(k) (F5) SELECT ITEM.
(l) (F1) CLOSE.
(m) SCOPE METER/MAIN MENU to display/highlight EXT.mV.
(5) RESET calibrator.
(6) Perform steps as listed in (a) through (d) below for each row in table 8.
(a) Under INPUT A pushbutton on left side, toggle (mV RANGE V) to display
TI Range settings.
(b) Set calibrator to Output volt settings.
(c) If TI Voltage indications are not within specified limit, perform b below.
(d) Set calibrator to standby.
Table 8. EXT.mV DC
Calibrator
Test instrument
Output volt settings
Range settings
Voltage indication
(V dc)
(V dc)
(V dc)
Min
Max
.3
300 m
298.0 m
302.0 m
3
3
2.980
3.020
(7) Select range settings by pressing pushbuttons sequence (a) through (h) below:
(a) SUB MENU.
(b) (F1) MORE EXT.mV.
(c) Toggle ▲ or ▼ to display/highlight to ADD MAIN READING.
(d) (F5) SELECT ITEM.
(e) Toggle ▲ or ▼ to display/highlight Vrms AC.
(f) (F5) SELECT ITEM.
(g) (F1) CLOSE).
(h) SCOPE METER/MAIN MENU to display SCOPE/METER/Ω/EXT.mV and etc.
(8) Perform steps as listed in (a) through (d) below for each row in table 9.
(a) Under INPUT A pushbutton on left side, toggle (mV RANGE V) to display
TI Range settings.
(b) Set calibrator to Output volt settings at 60 Hz.
(c) If TI voltage indications are not within specified limits, perform b below.
(d) Set calibrator to standby.
