TB 9-6625-1995-35
(17) Repeat technique of (14) through (16) above for settings listed in table 3. If
oscilloscope calibrator err display readout does not indicate within 2%, perform b below.
Test instrument
TIME/DIV OR DLY TIME
and DLY'D time/division
PULL FOR ALT
Oscilloscope calibrator marker
switch settings
output settings
20
ns
20
nS/D
50
ns
50
nS/D
s
S/D
.1
.1
s
S/D
.2
.2
s
S/D
.5
.5
s
S/D
1
1
s
S/D
2
2
s
S/D
5
5
s
S/D
10
10
s
S/D
20
20
s
S/D
50
50
.1
ms
.1
mS/D
.2
ms
.2
mS/D
.5
ms
.5
mS/D
1
ms
1
mS/D
2
ms
2
mS/D
5
ms
5
mS/D
10
ms
10
mS/D
20
ms
20
mS/D
50
ms
50
mS/D
.1
s
.1
S/D
.2
s
.2
S/D
(18) Position controls as listed in (a) through (c) below:
(a) TIME/DIV OR DLY TIME switch to .2 s.
(b) DLY'D time/division switch to 5 ms PUSH FOR DLY'D.
(c) DELAY TIME MULT dial to 0.90.
(19) Set oscilloscope calibrator MARKER output for .1 S/D.
(20) Adjust MAIN TRIGGERING LEVEL control for a stable display and position
vertical amplifier controls for approximately 2 divisions of display positioned in the center
graticule area.
(21) Adjust POSITION control to aline the time marker to the center vertical
graticule line.
(22) Adjust DELAY TIME MULT dial to approximately 8.90 to aline the time
marker to the center vertical graticule line. If DELAY TIME MULT dial indication is not
between 8.84 and 8.96, perform b below.
