SECTION II. EQUIPMENT REQUIREMENTS
Figure 1. Model 2200S (Series) - top view.

Calibration Procedure For Recorders, Ink Writing, Model 2200S (Series: With Rms Converter, Model 13-4618-10; And Frequency Deviation Converter, Model 13-4618-00 Page Navigation
  1    2    3  4  5    6    7    8    9
. . . . . . . .
TB 9-6625-2097-24
Table 2. Minimum Specifications of Equipment Required
AUTOTRANSFORMER
Range: 105 to 125 V ac
Ridge, Model 9020A (9020A)
Accuracy:  1%
CALIBRATOR
Frequency Range: DC to 400 Hz
Fluke, Model 5720A (5720A) (p/o
0.00625%
MIS-35947); w amplifier, Fluke
Accuracy:
5725A/AR (5725A/AR)
Amplitude Range: 0 to 10 V
Accuracy:  0.025%
FUNCTION/ARBITRARY
Frequency Range: 1 to 400 Hz
Agilent, Model 33250A (33250A)
0.00625%
GENERATOR
Accuracy:
Amplitude Range: 0 to 4 Vp-p
1%
Flatness:
MULTIMETER
Range: 0 to 5.025 V
Fluke, Model 8840A/AF05
Accuracy: 0.1%
(AN/GSM-64D)
SECTION III
CALIBRATION PROCESS FOR RECORDERS, INK WRITING
GOULD, MODEL 2200S (SERIES)
6. Preliminary Instructions
a. The instructions outlined in paragraphs 6 and 7 are preparatory to the calibration
process. Personnel should become familiar with the entire bulletin before beginning the
calibration.
b. Items of equipment used in this procedure are referenced within the text by common
name as listed in table 2.
c. Unless otherwise specified, verify the result of each test and, whenever the test
requirement is not met, take corrective action before continuing with the calibration.
Adjustments required to calibrate the TI are included in this procedure. Additional
maintenance information is contained in the manufacturer's manual for this TI.
d. Unless otherwise specified, all controls and control settings refer to the TI.
7. Equipment Setup
WARNING
HIGH VOLTAGE is used or exposed during the performance of
this calibration.
DEATH ON CONTACT may result if
personnel fail to observe safety precautions.
REDUCE
OUTPUT(S)  to  minimum  after  each setup within the
performance check where applicable.
a. Remove top protective cover from TI.
b. Slide all manual ink valves with tubing attached to ON position.
c. Remove preamplifiers from CH 1 and CH 2 of TI.
d. Press STOP pushbutton.
e. Connect TI to autotransformer.
f. Connect autotransformer to 115 V ac source and adjust for 115 V.
4
