TB 9-6625-113-24
Table 6. Capacitance Accuracy 1000 pF Steps (1 kHz).
TI
Impedance measuring system
Decade position
Min (pF)
Measured
Max (pF)
1
998.00
1002.0
2
1997.0
2003.0
3
2996.0
3004.0
4
3995.0
4005.0
5
4994.0
5006.0
6
5993.0
6007.0
7
6992.0
7008.0
8
7991.0
8009.0
9
8990.0
9010.0
10
9989.0
10011
Table 7. Capacitance Accuracy 0.01F Steps (1 kHz).
TI
Impedance measuring system
Decade position
Min (nF)
Measured
Max (nF)
1
9.9890
10.011
2
19.979
20.021
3
29.969
30.031
4
39.959
40.041
5
49.949
50.051
6
59.939
60.061
7
69.929
70.071
8
79.919
80.081
9
89.909
90.091
10
99.899
100.10
Table 8. Capacitance Accuracy 0.1F Steps (1 kHz).
TI
Impedance measuring system
Decade position
Min (nF)
Measured
Max (nF)
1
99.899
100.10
2
199.80
200.20
3
299.70
300.30
4
399.60
400.40
5
499.50
500.50
6
599.40
600.60
7
699.30
700.70
8
799.20
800.80
9
899.10
900.90
10
999.00
1001.0
(7) Disconnect equipment set-up.
b. Adjustments
NOTE
Only the 1 pF, 10 pF, 100 pF and 1000 pF ranges are
adjustable. If an out of tolerance condition exists on any other
range, the TI must be repaired.
8
